20AWG USB Type C to C 3A Charger Cable Data Transfer Lead - White

Original price £4.99 - Original price £7.99
Original price
£4.99
£4.99 - £7.99
Current price £4.99
SKU TTV1-MB31-MB31-WHT-0.5M
Length: 0.5m

20AWG Type C to Type C, 3A Cables are compatible with Qualcomm® Quick Charge™ 3.0 and backward compliant with older versions of Quick Charge™ as well as standard 5V charging under USB PD1.0.

For more information on USB-C Power Delivery visit http://www.usb.org/developers/powerdelivery

Primary Features:
  • Supports Standard (5v) & USB-C PD Fast Charging.
  • Premium Quality, Low Resistance 20AWG Pure Tinned Copper Core
  • USB-C Profile: Profile 2, 18W, 3A
WARNING: Non-certified cables can harm your device.
These have a 56kΩ Pull Up Resistor and abide to the correct power and data transfer speeds as follows:
  • Connected to USB-C Data Port: 500ma (max), 480mbps (USB2.0 Specification)
  • Direct Charging: Up to 3A (max)
Specifications:
  • American Wire Gauge (AWG): 20C/28D (C=Charge, D=Data)
  • Connector 1: Male USB Type-C (2.0) 24 Pin; Gold Plated Pins
  • Connector 2: Male USB Type-C (2.0) 24 Pin; Gold Plated Pins
  • Conductor: Pure Tinned Copper
  • Aluminium Mylar Foil Shield: 15um
  • Jacket: PVC 60P, Half Matt
  • Diameter: 4.0mm +/- 0.1mm
  • Max Conductor Resistance at 20°C (Ω/Km): 109.2Ω
  • Tensile Strength (Kgf/mm²): 2.11 / =70% of original
  • CertificationsCE/ROHS, FCC
  • USB Electronic Testing: (Cert#11632/16-09-EAX-003-E00)
  • Pull Up Resistor: Yes, 56kΩ
  • Fastener Included: Yes, Velcro
  • Warranty: 18 Months.
    Compatibility:

    All manufacturers will state in their manuals what cable is used, or you can find the information on sites such GSM Arena or you can email us hello@juicebitz.co.uk or call 01723 332269 and one of our advisers will be happy to help.
